View In:   ArcGIS Online Map Viewer

Name: BLM CA PLSS Corners Point

Display Field: PLSSID

Type: Feature Layer

Geometry Type: esriGeometryPoint

Description: These are the cadastral reference features that provide the basis and framework for parcel mapping and for other mapping. This feature data set contains PLSS and Other Survey System data. The other survey systems include subdivision plats and those types of survey reference systems. This feature data set also include feature classes to support the special conditions in Ohio. This data set represents the GIS Version of the Public Land Survey System including both rectangular and non-rectangular surveys. The primary source for the data is cadastral survey records housed by the BLM supplemented with local records and geographic control coordinates from states, counties as well as other federal agencies such as the USGS and USFS. The data has been converted from source documents to digital form and transferred into a GIS format that is compliant with FGDC Cadastral Data Content Standards and Guidelines for publication. This data is optimized for data publication and sharing rather than for specific "production" or operation and maintenance. This data set includes the following: PLSS Fully Intersected (all of the PLSS feature at the atomic or smallest polygon level), PLSS Townships, First Divisions and Second Divisions (the hierarchical break down of the PLSS Rectangular surveys) PLSS Special surveys (non rectangular components of the PLSS) Meandered Water, Corners and Conflicted Areas (known areas of gaps or overlaps between Townships or state boundaries). The Entity-Attribute section of this metadata describes these components in greater detail.

Copyright Text: U.S. Department of the Interior, Bureau of Land Management (BLM), California State Office

Default Visibility: true

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 100000

Max Scale: 0

Supports Advanced Queries: true

Supports Statistics: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports ValidateSQL: true

Supports Calculate: true

Supports Datum Transformation: true

Extent:

XMin: -373867.05120000057
YMin: -604494.5782000003
XMax: 540041.7386999987
YMax: 450028.35639999993
Spatial Reference: 3310  (3310)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSMSCircle
Color: [0, 0, 0, 255]
Size: 4.0
Angle: 0.0
XOffset: 0
YOffset: 0
Outline:
[0, 0, 0, 255] Width: 0
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: true
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: false
Supports Sql Format: false
Supports Query Analytic: true
Supports Query With Current User: true

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeNone

Type ID Field:

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID, editable: false, nullable: false, defaultValue: null, modelName: System-maintained ObjectID )
• PLSSID ( type: esriFieldTypeString, alias: Township Identifier, editable: true, nullable: true, length: 16, defaultValue: null, modelName: PLSSID )
• POINTID ( type: esriFieldTypeString, alias: Corner Point ID, editable: true, nullable: true, length: 25, defaultValue: null, modelName: POINTID )
• POINTLAB ( type: esriFieldTypeString, alias: Corner Point Label, editable: true, nullable: true, length: 25, defaultValue: null, modelName: POINTLAB )
• XCOORD ( type: esriFieldTypeDouble, alias: X or East Coordinate, editable: true, nullable: true, defaultValue: null, modelName: XCOORD )
• YCOORD ( type: esriFieldTypeDouble, alias: Y or North Coordinate, editable: true, nullable: true, defaultValue: null, modelName: YCOORD )
• ZCOORD ( type: esriFieldTypeDouble, alias: Z or Height Coordinate, editable: true, nullable: true, defaultValue: null, modelName: ZCOORD )
• ELEV ( type: esriFieldTypeDouble, alias: Average Township Elevation, editable: true, nullable: true, defaultValue: null, modelName: ELEV )
• RELYTXT ( type: esriFieldTypeString, alias: Reliability Text, editable: true, nullable: true, length: 25, defaultValue: null, modelName: RELYTXT )
• RELYNUMB ( type: esriFieldTypeDouble, alias: Reliability Number, editable: true, nullable: true, defaultValue: null, modelName: RELYNUMB )
• ERRORX ( type: esriFieldTypeDouble, alias: Error in X, editable: true, nullable: true, defaultValue: null, modelName: ERRORX )
• ERRORY ( type: esriFieldTypeDouble, alias: Error in Y, editable: true, nullable: true, defaultValue: null, modelName: ERRORY )
• ERRORZ ( type: esriFieldTypeDouble, alias: Error in Z, editable: true, nullable: true, defaultValue: null, modelName: ERRORZ )
• HDATUM ( type: esriFieldTypeString, alias: Horizontal Datum, editable: true, nullable: true, length: 20, defaultValue: null, modelName: HDATUM )
• VDATUM ( type: esriFieldTypeString, alias: Vertical Datum, editable: true, nullable: true, length: 20, defaultValue: null, modelName: VDATUM )
• COORDMETH ( type: esriFieldTypeString, alias: Coordinate Collection Method, editable: true, nullable: true, length: 25, defaultValue: null, modelName: COORDMETH )
• COORDSYS ( type: esriFieldTypeString, alias: Coordinate System, editable: true, nullable: true, length: 50, defaultValue: null, modelName: COORDSYS )
• STEWARD1 ( type: esriFieldTypeString, alias: Data Steward, editable: true, nullable: true, length: 50, defaultValue: null, modelName: STEWARD1 )
• STEWARD2 ( type: esriFieldTypeString, alias: Second Data Steward, editable: true, nullable: true, length: 50, defaultValue: null, modelName: STEWARD2 )
• LOCAL1 ( type: esriFieldTypeString, alias: First PLSS Point Alternate Name, editable: true, nullable: true, length: 25, defaultValue: null, modelName: LOCAL1 )
• LOCAL2 ( type: esriFieldTypeString, alias: Second PLSS Point Alternate Name, editable: true, nullable: true, length: 25, defaultValue: null, modelName: LOCAL2 )
• LOCAL3 ( type: esriFieldTypeString, alias: Third PLSS Point Alternate Name, editable: true, nullable: true, length: 25, defaultValue: null, modelName: LOCAL3 )
• LOCAL4 ( type: esriFieldTypeString, alias: Fourth PLSS Point Alternate Name, editable: true, nullable: true, length: 25, defaultValue: null, modelName: LOCAL4 )
• SURVEYYEAR ( type: esriFieldTypeInteger, alias: Survey Year, editable: true, nullable: true, defaultValue: null, modelName: SURVEYYEAR )
• REVISEDDATE ( type: esriFieldTypeDate, alias: Revised Date, editable: true, nullable: true, length: 8, defaultValue: null, modelName: REVISEDDATE )
• last_edited_date ( type: esriFieldTypeDate, alias: last_edited_date, editable: false, nullable: true, length: 8, defaultValue: null, modelName: last_edited_date )
• GlobalID ( type: esriFieldTypeGlobalID, alias: GlobalID, editable: false, nullable: false, length: 38, defaultValue: null, modelName: GlobalID )

Templates:

• Name: BLM CA Corners Public Land Survey System
  Description:
  Prototype:
  REVISEDDATE: null
  PLSSID: null
  POINTID: null
  POINTLAB: null
  XCOORD: null
  YCOORD: null
  ZCOORD: null
  ELEV: null
  RELYTXT: null
  RELYNUMB: null
  ERRORX: null
  ERRORY: null
  ERRORZ: null
  HDATUM: null
  VDATUM: null
  COORDMETH: null
  COORDSYS: null
  STEWARD1: null
  STEWARD2: null
  LOCAL1: null
  LOCAL2: null
  LOCAL3: null
  LOCAL4: null
  SURVEYYEAR: null

  Drawing Tool: esriFeatureEditToolPoint

Capabilities: Query,Extract

Sync Can Return Changes: false

Is Data Versioned: false

Supports Rollback On Failure: true

Supports ApplyEdits With Global Ids: true

Edit Fields Info:

• Creation Date Field: created_date
• Creator Field: created_user
• Edit Date Field: last_edited_date
• Editor Field: last_edited_user

Supports Query With Historic Moment: false

Supports Coordinates Quantization: true

Child Resources:   Field Groups   Contingent Values

Supported Operations:   Query   Query Analytic   Validate SQL   Generate Renderer   Return Updates   Iteminfo   Thumbnail   Metadata   Update Metadata
