View In:   ArcGIS Online Map Viewer

Name: BLM CA Land Grants Public Land Survey System

Display Field: SURVTYP

Type: Feature Layer

Geometry Type: esriGeometryPolygon

Description: These are the cadastral reference features that provide the basis and framework for parcel mapping and for other mapping. This feature data set contains PLSS and Other Survey System data. The other survey systems include subdivision plats and those types of survey reference systems. This feature data set also include feature classes to support the special conditions in Ohio. This data set represents the GIS Version of the Public Land Survey System including both rectangular and non-rectangular surveys. The primary source for the data is cadastral survey records housed by the BLM supplemented with local records and geographic control coordinates from states, counties as well as other federal agencies such as the USGS and USFS. The data has been converted from source documents to digital form and transferred into a GIS format that is compliant with FGDC Cadastral Data Content Standards and Guidelines for publication. This data is optimized for data publication and sharing rather than for specific "production" or operation and maintenance. This data set includes the following: PLSS Fully Intersected (all of the PLSS feature at the atomic or smallest polygon level), PLSS Townships, First Divisions and Second Divisions (the hierarchical break down of the PLSS Rectangular surveys) PLSS Special surveys (non rectangular components of the PLSS) Meandered Water, Corners and Conflicted Areas (known areas of gaps or overlaps between Townships or state boundaries). The Entity-Attribute section of this metadata describes these components in greater detail.

Copyright Text: These data are provided by Bureau of Land Management (BLM) “as is” and might contain errors or omissions. The User assumes the entire risk associated with its use of these data and bears all responsibility in determining whether these data are fit for the User’s intended use. The information contained in these data is dynamic and may change over time. The data are not better than the sources from which they were derived, and both scale and accuracy may vary across the data set. These data might not have the accuracy, resolution, completeness, timeliness, or other characteristics appropriate for applications that potential users of the data may contemplate. The User is encouraged to carefully consider the content of the metadata file associated with these data. These data are neither legal documents nor land surveys, and must not be used as such. Official records may be referenced at most BLM offices. Please report any errors in the data to the BLM office from which it was obtained. The BLM should be cited as the data source in any products derived from these data. Any Users wishing to modify the data should describe the types of modifications they have performed. The User should not misrepresent the data, nor imply that changes made were approved or endorsed by BLM. This data may be updated by the BLM without notification.

Default Visibility: true

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 500000

Max Scale: 0

Supports Advanced Queries: true

Supports Statistics: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports ValidateSQL: true

Supports Calculate: true

Supports Datum Transformation: true

Extent:

XMin: -368613.35909999907
YMin: -599283.3570999997
XMax: 529645.2303999998
YMax: 448824.2829
Spatial Reference: 3310  (3310)

Drawing Info:

Renderer:
Unique Value Renderer:
Field 1: SURVTYP
Field 2: N/A
Field 3: N/A
Field Delimiter: ,
Default Symbol:
N/A
Default Label: N/A
UniqueValueInfos:
• Value: G
  Label: Land Grants
  Description: N/A
  Symbol:
  Style: esriSFSDiagonalCross
  Color: [76, 230, 0, 255]
  Outline:
  Style: esriSLSSolid
  Color: [38, 115, 0, 255]
  Width: 0
Transparency: 0
Labeling Info:
Label Placement: esriServerPolygonPlacementAlwaysHorizontal
Label Expression: [SURVLAB] CONCAT NEWLINE CONCAT "Land Grant"
Use Coded Values: true
Symbol:
Color: [0, 115, 76, 255]
Background Color: N/A
Outline Color: N/A
Vertical Alignment: baseline
Horizontal Alignment: left
Right to Left: false
Angle: 0
XOffset: 0
YOffset: 0
Size: 12
Font Family: Arial
Font Style: normal
Font Weight: normal
Font Decoration: none

Min. Scale: 0.0
Max. Scale: 0.0

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: true
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeNone

Type ID Field: SURVTYP

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID, editable: false, nullable: false, defaultValue: null, modelName: System-maintained ObjectID )
• SURVTYP ( type: esriFieldTypeString, alias: PLSS Special Survey Type Code, editable: true, nullable: true, length: 2, defaultValue: null, modelName: SURVTYP )
• SURVTYPTXT ( type: esriFieldTypeString, alias: PLSS Special Survey Type Text, editable: true, nullable: true, length: 50, defaultValue: null, modelName: SURVTYPTXT )
• SURVNO ( type: esriFieldTypeString, alias: PLSS Special Survey Number, editable: true, nullable: true, length: 50, defaultValue: null, modelName: SURVNO )
• SURVSUF ( type: esriFieldTypeString, alias: PLSS Special Survey Suffix, editable: true, nullable: true, length: 5, defaultValue: null, modelName: SURVSUF )
• SURVNOTE ( type: esriFieldTypeString, alias: PLSS Special Survey Type Note, editable: true, nullable: true, length: 50, defaultValue: null, modelName: SURVNOTE )
• SURVLAB ( type: esriFieldTypeString, alias: PLSS Special Survey Note, editable: true, nullable: true, length: 50, defaultValue: null, modelName: SURVLAB )
• SURVID ( type: esriFieldTypeString, alias: Survey Identifier, editable: true, nullable: true, length: 50, defaultValue: null, modelName: SURVID )
• SURVDIV ( type: esriFieldTypeString, alias: Special Survey Division, editable: true, nullable: true, length: 50, defaultValue: null, modelName: SURVDIV )
• SOURCEREF ( type: esriFieldTypeString, alias: Source Doc Link or Reference, editable: true, nullable: true, length: 100, defaultValue: null, modelName: SOURCEREF )
• SOURCEDATE ( type: esriFieldTypeDate, alias: Source Doc Date, editable: true, nullable: true, length: 8, defaultValue: null, modelName: SOURCEDATE )
• RECRDAREATX ( type: esriFieldTypeString, alias: Record Area Text, editable: true, nullable: true, length: 20, defaultValue: null, modelName: RECRDAREATX )
• RECRDAREANO ( type: esriFieldTypeDouble, alias: Record Area Number, editable: true, nullable: true, defaultValue: null, modelName: RECRDAREANO )
• GISACRE ( type: esriFieldTypeDouble, alias: GIS Area Acres, editable: true, nullable: true, defaultValue: null, modelName: GISACRE )
• last_edited_date ( type: esriFieldTypeDate, alias: last_edited_date, editable: false, nullable: true, length: 8, defaultValue: null, modelName: last_edited_date )
• GlobalID ( type: esriFieldTypeGlobalID, alias: GlobalID, editable: false, nullable: false, length: 38, defaultValue: null, modelName: GlobalID )

Types:

ID: G
Name: Land Grants
Domains:
Templates:
• Name: G
  Description:
  Prototype:
  RECRDAREANO: null
  GISACRE: null
  SURVTYP: G
  SURVTYPTXT: null
  SURVNO: null
  SURVSUF: null
  SURVNOTE: null
  SURVLAB: null
  SURVID: null
  SURVDIV: null
  SOURCEREF: null
  SOURCEDATE: null
  RECRDAREATX: null

  Drawing Tool: esriFeatureEditToolPolygon

---

Capabilities: Query,Extract

Sync Can Return Changes: false

Is Data Versioned: false

Supports Rollback On Failure: true

Supports ApplyEdits With Global Ids: true

Edit Fields Info:

• Creation Date Field: created_date
• Creator Field: created_user
• Edit Date Field: last_edited_date
• Editor Field: last_edited_user

Supports Query With Historic Moment: false

Supports Coordinates Quantization: true

Supported Operations:   Query   Query Attachments   Query Analytic   Calculate   Validate SQL   Generate Renderer   Return Updates   Iteminfo   Thumbnail   Metadata
