View In:   ArcGIS Online Map Viewer

Name: BLM ID State Boundary GCDB Line Hub

Display Field: CREATE_BY

Type: Feature Layer

Geometry Type: esriGeometryPolyline

Description: This dataset portrays the state boundary based on the 2010 Cadastral National Spatial Data Infrastructure (CADNSDI) Geographic Coordinate Data Base (GCDB) distribution. The GCDB was acquired from a Premier Data contract in coordination with the BLM state GCDB Data Stewards to deliver a standardized GCDB product. This product would be capable, where GCDB data exists, to identify the State borders. Where GCDB data does not exist, in cases or rivers, lakes, and unsurveyed terrain, then alternative sources were used to identify the state boundary. Alternative sources include original 24K USGS Maps and US Forest Service Cartographic Feature File (CFF) PLSS data.

Copyright Text: United States Department of Interior, Bureau of Land Management.

Default Visibility: true

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0

Max Scale: 0

Supports Advanced Queries: true

Supports Statistics: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports ValidateSQL: true

Supports Calculate: true

Supports Datum Transformation: true

Extent:

XMin: 2241698.8913000003
YMin: 1198696.3348999992
XMax: 2744589.3060999997
YMax: 1982021.3310000002
Spatial Reference: 102605  (8826)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSLSSolid
Color: [52, 130, 122, 255]
Width: 1
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: true
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: false
Supports Sql Format: false
Supports Query Analytic: true
Supports Query With Current User: true

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field:

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID, editable: false, nullable: false, defaultValue: null, modelName: OBJECTID )
• CREATE_DATE ( type: esriFieldTypeDate, alias: CREATE_DATE, editable: true, nullable: true, length: 8, defaultValue: null, modelName: CREATE_DATE )
• CREATE_BY ( type: esriFieldTypeString, alias: CREATE_BY, editable: true, nullable: true, length: 30, defaultValue: null, modelName: CREATE_BY )
• MODIFY_DATE ( type: esriFieldTypeDate, alias: MODIFY_DATE, editable: true, nullable: true, length: 8, defaultValue: null, modelName: MODIFY_DATE )
• MODIFY_BY ( type: esriFieldTypeString, alias: MODIFY_BY, editable: true, nullable: true, length: 30, defaultValue: null, modelName: MODIFY_BY )
• COORD_SRC_TYPE ( type: esriFieldTypeString, alias: COORD_SRC_TYPE, editable: true, nullable: true, length: 5, defaultValue: null, modelName: COORD_SRC_TYPE , Coded Values: [CFF: Cartographic Feature Files] , [DEM: Digital Elevation Model] , [DLG: Digital Line Graph] , ...13 more... )
• COORD_SRC2 ( type: esriFieldTypeString, alias: COORD_SRC2, editable: true, nullable: true, length: 25, defaultValue: null, modelName: COORD_SRC2 )
• DEF_FET_TYPE ( type: esriFieldTypeString, alias: DEF_FET_TYPE, editable: true, nullable: true, length: 15, defaultValue: null, modelName: DEF_FET_TYPE , Coded Values: [ADMIN_BND: Administrative Boundary] , [COAST_FLUV: Coastal Fluvial Landform] , [CONST_FEAT: Constructed Feature] , ...6 more... )
• DEF_FET2 ( type: esriFieldTypeString, alias: DEF_FET2, editable: true, nullable: true, length: 30, defaultValue: null, modelName: DEF_FET2 )
• ACCURACY_FT ( type: esriFieldTypeInteger, alias: ACCURACY_FT, editable: true, nullable: true, defaultValue: null, modelName: ACCURACY_FT )
• ADMIN_ST ( type: esriFieldTypeString, alias: ADMIN_ST, editable: true, nullable: true, length: 2, defaultValue: null, modelName: ADMIN_ST , Coded Values: [AK: Alaska] , [AZ: Arizona] , [CA: California] , ...9 more... )
• Comments ( type: esriFieldTypeString, alias: Comments, editable: true, nullable: true, length: 250, defaultValue: null, modelName: Comments )
• GlobalID ( type: esriFieldTypeGlobalID, alias: GlobalID, editable: false, nullable: false, length: 38, defaultValue: null, modelName: GlobalID )
• Shape__Length ( type: esriFieldTypeDouble, alias: Shape.STLength(), editable: false, nullable: true, defaultValue: null, modelName: Shape.STLength(), required: true )

Templates:

• Name: BLM ID State Boundary GCDB Line Hub
  Description:
  Prototype:
  ADMIN_ST: null
  Comments: null
  CREATE_DATE: null
  CREATE_BY: null
  MODIFY_DATE: null
  MODIFY_BY: null
  COORD_SRC_TYPE: null
  COORD_SRC2: null
  DEF_FET_TYPE: null
  DEF_FET2: null
  ACCURACY_FT: null

  Drawing Tool: esriFeatureEditToolLine

Capabilities: Query,Extract

Sync Can Return Changes: false

Is Data Versioned: false

Supports Rollback On Failure: true

Supports ApplyEdits With Global Ids: true

Supports Query With Historic Moment: false

Supports Coordinates Quantization: true

Child Resources:   Field Groups   Contingent Values

Supported Operations:   Query   Query Analytic   Validate SQL   Generate Renderer   Return Updates   Iteminfo   Thumbnail   Metadata   Update Metadata
