View In:   ArcGIS Online Map Viewer

Name: BLM ID State Boundary GCDB Poly Hub

Display Field: STATE

Type: Feature Layer

Geometry Type: esriGeometryPolygon

Description: This dataset portrays the state boundary based on the 2010 Cadastral National Spatial Data Infrastructure (CADNSDI) Geographic Coordinate Data Base (GCDB) distribution. The GCDB was acquired from a Premier Data contract in coordination with the BLM state GCDB Data Stewards to deliver a standardized GCDB product. This product would be capable, where GCDB data exists, to identify the State borders. Where GCDB data does not exist, in cases or rivers, lakes, and unsurveyed terrain, then alternative sources were used to identify the state boundary. Alternative sources include original 24K USGS Maps and US Forest Service Cartographic Feature File (CFF) PLSS data.

Copyright Text: United States Department of Interior, Bureau of Land Management.

Default Visibility: true

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0

Max Scale: 0

Supports Advanced Queries: true

Supports Statistics: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports ValidateSQL: true

Supports Calculate: true

Supports Datum Transformation: true

Extent:

XMin: 2241698.8913000003
YMin: 1198696.3348999992
XMax: 2744589.3060999997
YMax: 1982021.3310000002
Spatial Reference: 102605  (8826)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSFSSolid
Color: [252, 232, 201, 255]
Outline:
Style: esriSLSSolid
Color: [110, 110, 110, 255]
Width: 0
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: true
Supports Returning Geometry Centroid: true
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: false
Supports Sql Format: false
Supports Query Analytic: true
Supports Query With Current User: true

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field:

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID, editable: false, nullable: false, defaultValue: null, modelName: OBJECTID )
• STATE ( type: esriFieldTypeString, alias: STATE, editable: true, nullable: true, length: 30, defaultValue: null, modelName: STATE )
• STATE_CODE ( type: esriFieldTypeString, alias: STATE_CODE, editable: true, nullable: true, length: 2, defaultValue: null, modelName: STATE_CODE , Coded Values: [AK: Alaska] , [AZ: Arizona] , [CA: California] , ...9 more... )
• STATE_ID ( type: esriFieldTypeSmallInteger, alias: STATE_ID, editable: true, nullable: true, defaultValue: null, modelName: STATE_ID )
• GlobalID ( type: esriFieldTypeGlobalID, alias: GlobalID, editable: false, nullable: false, length: 38, defaultValue: null, modelName: GlobalID )
• Shape__Area ( type: esriFieldTypeDouble, alias: Shape.STArea(), editable: false, nullable: true, defaultValue: null, modelName: Shape.STArea(), required: true )
• Shape__Length ( type: esriFieldTypeDouble, alias: Shape.STLength(), editable: false, nullable: true, defaultValue: null, modelName: Shape.STLength(), required: true )

Templates:

• Name: BLM ID State Boundary GCDB Poly Hub
  Description:
  Prototype:
  STATE_ID: null
  STATE_CODE: null
  STATE: null

  Drawing Tool: esriFeatureEditToolPolygon

Capabilities: Query,Extract

Sync Can Return Changes: false

Is Data Versioned: false

Supports Rollback On Failure: true

Supports ApplyEdits With Global Ids: true

Supports Query With Historic Moment: false

Supports Coordinates Quantization: true

Child Resources:   Field Groups   Contingent Values

Supported Operations:   Query   Query Analytic   Validate SQL   Generate Renderer   Return Updates   Iteminfo   Thumbnail   Metadata   Update Metadata
