Name: BLM ID Right Of Way Line

Display Field: CASEFILE

Type: Feature Layer

Geometry Type: esriGeometryPolyline

Description: These are Rights-of-Ways (ROW) on Idaho BLM land (and some other Federal agency land) as shown on Bureau of Land Management (BLM) Master Title Plats (MTP). Every GIS ROW feature has a "CASEFILE" value, also known as the serial number of the ROW. The ROW data that was digitized is what was present on the MTP at the time of the digitizing done for that township. The project was performed over several years. Therefore, the "early" townships digitized are more out of date regarding ROWs compared to the ones more recently digitized. Unfortunately, there is no attribute that indicates the digitizing sequence. Any updates to this ROW feature class should be sent to the BLM Idaho State Office GIS staff for incorporation into the statewide GIS ROW feature classes for improvement over time. For more information contact us at [email protected].

Copyright Text: Bureau of Land Management (BLM), Idaho State Office

Default Visibility: true

MaxRecordCount: 2000

MaxSelectionCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 2242304.9030999998
YMin: 1199072.7814000007
XMax: 2744053.4297
YMax: 1980235.3223
Spatial Reference: 102605  (8826)  LatestVCSWkid(0)

Drawing Info:

Renderer:
Unique Value Renderer:
Field 1: DIG_CATGRY
Field 2: N/A
Field 3: N/A
Field Delimiter: ,
Default Symbol:
Style: esriSLSSolid
Color: [78, 78, 78, 255]
Width: 2
Default Label: Other or Unknown
UniqueValueInfos:
• Value: Pipeline
  Label: Pipeline
  Description: Pipeline
  Symbol:
  Style: esriSLSSolid
  Color: [0, 0, 0, 255]
  Width: 4
• Value: Power
  Label: Power
  Description: Power
  Symbol:
  Style: esriSLSSolid
  Color: [130, 130, 130, 255]
  Width: 4
• Value: Railroad
  Label: Railroad
  Description: Railroad
  Symbol:
  Style: esriSLSSolid
  Color: [0, 0, 0, 255]
  Width: 0
• Value: Road
  Label: Road
  Description: Road
  Symbol:
  Style: esriSLSDash
  Color: [168, 56, 0, 255]
  Width: 1
• Value: Telephone or Telegraph
  Label: Telephone or Telegraph
  Description: Telephone or Telegraph
  Symbol:
  Style: esriSLSSolid
  Color: [0, 0, 0, 255]
  Width: 2
• Value: Water
  Label: Water
  Description: Water
  Symbol:
  Style: esriSLSDash
  Color: [102, 153, 205, 255]
  Width: 1
• Value: General
  Label: General
  Description: General
  Symbol:
  Style: esriSLSSolid
  Color: [156, 156, 156, 255]
  Width: 2
Transparency: 0
Labeling Info:

Feature Draw Order:

N/A

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: true
Supports Sql Format: false
Supports Query Analytic: true
Supports Query With Current User: true

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• CASEFILE ( type: esriFieldTypeString, alias: CASEFILE, length: 17 )
• SOURCE ( type: esriFieldTypeString, alias: SOURCE, length: 50 )
• COMMENT ( type: esriFieldTypeString, alias: COMMENT, length: 100 )
• ROW_WIDTH ( type: esriFieldTypeInteger, alias: ROW_WIDTH )
• GIS_ACRES ( type: esriFieldTypeDouble, alias: GIS_ACRES )
• GIS_LENGTH ( type: esriFieldTypeDouble, alias: GIS_LENGTH )
• DIG_CATGRY ( type: esriFieldTypeString, alias: DIG_CATGRY, length: 50 )
• GlobalID ( type: esriFieldTypeGlobalID, alias: GlobalID, length: 38 )
• Shape ( type: esriFieldTypeGeometry, alias: Shape )
• Shape.STLength() ( type: esriFieldTypeDouble, alias: Shape.STLength() )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
